Exclusive Offer Phoenix Contact 3208197 Feed-through terminal block PT 1,5/S-QUATTRO

Exclusive Offer Phoenix Contact 3208197 Feed-through terminal block PT 1,5/S-QUATTRO

Original price was: $1.79.Current price is: $0.90.

SKU: SK0063211-US20260519-084255 Category: Tag:

Description

Phoenix Contact 3208197 A feed-through terminal block with a nominal voltage of 500 V and a nominal current capacity of 17.5 A is available, featuring four push-in connections. The rated cross-sectional area is 1.5 mm², with an actual cross-sectional area ranging from 0.14 to 1.5 mm². This terminal block is mounted using the NS 35/7.5 and NS 35/15 systems, and its color is gray.

Specifications

Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
500 Volt
Terminal Block Fused
Not Fused
Terminal Block Number of Levels
1
Terminal Block Number of Connections
4
Terminal Block Width
3.5 mm
Terminal Block Component Color
Gray
Terminal Block Grounded
Not Grounded
Terminal Block Min Wire Size
26
Terminal Block Connection Method
Push-In Connection
Terminal Block Max Wire Size
14
Terminal Block Amperage
17.5 Amp
Component
Terminal Block
Manufacturer
Phoenix Contact
Sub Component
Feed-Through Terminal Block
Sub Component
Multi-Conductor Terminal Block
