Phoenix Contact 3208161 Feed-through terminal block PT 1,5/S-TWIN BN Premium

Phoenix Contact 3208161 Feed-through terminal block PT 1,5/S-TWIN BN Premium

Original price was: $1.68.Current price is: $0.84.

SKU: SK0063210-US20260519-084255 Category: Tag:

Description

Phoenix Contact 3208161 The feed-through terminal block has a nominal voltage of 500 V and can handle a nominal current of up to 17.5 A. It features three push-in connections with rated cross-sections ranging from 0.14 mm2 to 1.5 mm2 per level, mounting types include NS 35/7,5 and NS 35/15, and has a brown color designation.

Specifications

Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
500 Volt
Terminal Block Fused
Not Fused
Terminal Block Number of Levels
1
Terminal Block Width
3.5 mm
Terminal Block Number of Connections
3
Terminal Block Grounded
Not Grounded
Terminal Block Min Wire Size
26
Terminal Block Connection Method
Push-In Connection
Terminal Block Max Wire Size
14
Terminal Block Component Color
Brown
Terminal Block Amperage
17.5 Amp
Component
Terminal Block
Manufacturer
Phoenix Contact
Sub Component
Feed-Through Terminal Block
Sub Component
Multi-Conductor Terminal Block
