Genuine Phoenix Contact 3248100 Mini feed-through terminal block MPT 1,5/S

Genuine Phoenix Contact 3248100 Mini feed-through terminal block MPT 1,5/S

Original price was: $1.06.Current price is: $0.53.

SKU: SK0063194-US20260519-084255 Category: Tag:

Description

Phoenix Contact 3248100 A mini feed-through terminal block with specific characteristics is available, featuring a nominal voltage of 500 V and a maximum current capacity of 17.5 A, accommodating two connections that can be secured via push-in connection. The rated cross-sectional area for each level ranges from 0.14 mm2 to 1.5 mm2, allowing for secure mounting using the NS 15 type, with an overall color tone of gray.

Specifications

Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
500 Volt
Terminal Block Fused
Not Fused
Terminal Block Number of Levels
1
Terminal Block Number of Connections
2
Terminal Block Width
3.5 mm
Terminal Block Component Color
Gray
Terminal Block Grounded
Not Grounded
Terminal Block Min Wire Size
26
Terminal Block Connection Method
Push-In Connection
Terminal Block Max Wire Size
14
Terminal Block Amperage
17.5 Amp
Component
Terminal Block
Manufacturer
Phoenix Contact
Sub Component
Miniature Terminal Block
Sub Component
Mini Feed-Through Terminal Block
