Popular Phoenix Contact 3037410 Feed-through terminal block ST 2,5-QUATTRO RD

Popular Phoenix Contact 3037410 Feed-through terminal block ST 2,5-QUATTRO RD

Original price was: $2.91.Current price is: $1.46.

SKU: SK0073561-US20260519-084255 Category: Tag:

Description

Phoenix Contact 3037410 The feed-through terminal block has a nominal voltage of 800 V and a nominal current rating of 24 A, accommodating four connections via spring-cage connection. The cross-sectional area ranges from 0.08 mm2 to 4 mm2, with a rated cross-sectional area of 2.5 mm2, suitable for mounting types NS 35/7.5 and NS 35/15, and is colored red.

Specifications

Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
800 Volt
Terminal Block Fused
Not Fused
Terminal Block Width
5.2 mm
Terminal Block Number of Levels
1
Terminal Block Number of Connections
4
Terminal Block Grounded
Not Grounded
Terminal Block Max Wire Size
12
Terminal Block Connection Method
Spring-Cage Connection
Terminal Block Min Wire Size
28
Terminal Block Component Color
Red
Terminal Block Amperage
24 Amp
Component
Terminal Block
Manufacturer
Phoenix Contact
Sub Component
Feed-Through Terminal Block
Sub Component
Multi-Conductor Terminal Block
