Phoenix Contact 3211223 Feed-through terminal block PT 2,5-TWIN RD Time-Limited

Phoenix Contact 3211223 Feed-through terminal block PT 2,5-TWIN RD Time-Limited

Original price was: $1.78.Current price is: $0.89.

SKU: SK0063220-US20260519-084255 Category: Tag:

Description

Phoenix Contact 3211223 The feed-through terminal block has a nominal voltage of 800V and a maximum current rating of 24A, allowing for connections to be made via a push-in method. It features three connection points, with rated cross sections ranging from 0.14mm² to 4mm², while its mounting type is the NS35/7.5 or NS35/15 configurations, and it comes in red color.

Specifications

Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
800 Volt
Terminal Block Fused
Not Fused
Terminal Block Width
5.2 mm
Terminal Block Number of Levels
1
Terminal Block Number of Connections
3
Terminal Block Grounded
Not Grounded
Terminal Block Max Wire Size
12
Terminal Block Min Wire Size
26
Terminal Block Connection Method
Push-In Connection
Terminal Block Component Color
Red
Terminal Block Amperage
24 Amp
Component
Terminal Block
Manufacturer
Phoenix Contact
Sub Component
Feed-Through Terminal Block
Sub Component
Multi-Conductor Terminal Block
