Phoenix Contact 3012300 Multi-level terminal block PT 2,5-4L/1P One Day Deal

Phoenix Contact 3012300 Multi-level terminal block PT 2,5-4L/1P One Day Deal

Original price was: $11.14.Current price is: $5.57.

SKU: SK0063350-US20260519-084255 Category: Tag:

Description

Phoenix Contact 3012300 The terminal block features an 8-way push-in/plug connection, with a nominal voltage of 250V and a nominal current rating of 10A. It has a rated cross-sectional area of 2.5mm² but can accommodate smaller or larger cross-sections between 0.14mm² to 4mm², making it suitable for various applications. The block is designed with mounting types NS35/7.5 and NS35/15, and its outer casing has a gray color.

Specifications

Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
250 Volt
Terminal Block Fused
Not Fused
Terminal Block Width
5.2 mm
Terminal Block Number of Connections
8
Terminal Block Number of Levels
4
Terminal Block Component Color
Gray
Terminal Block Grounded
Not Grounded
Terminal Block Max Wire Size
12
Terminal Block Min Wire Size
26
Terminal Block Connection Method
Push-In Connection
Terminal Block Amperage
10 Amp
Component
Terminal Block
Manufacturer
Phoenix Contact
Sub Component
Multi-Level Terminal Block
Sub Component
Plug-In Terminal Block
