Phoenix Contact 1935459 PCB terminal block PT 1,5/16-5,0-V Mega Sale

Phoenix Contact 1935459 A printed circuit board terminal has specifications including a nominal current of 17.5 A, rated voltage of 400 V, and a cross-sectional area of 1.5 mm2. It has 16 potentials, arranged in a single row with 16 positions, and is part of the PT 1,5/..-V product range. The terminals have a pitch of 5 mm and use screw connections with wire protectors for wave soldering mounting, with the conductor/PCB connection direction at 90 degrees. The color of the terminals is green, and they feature linear pinning with solder pins measuring 3.5 mm in length, one per potential. The terminals are packaged in cardboard.
