Phoenix Contact 1711084 PCB terminal block MKDS 3/ 8 Latest

Phoenix Contact 1711084 A printed circuit board terminal has a nominal current rating of 24 A and is designed for use with a 400 V rated voltage (III/2). It features a 2.5 mm2 cross-sectional area, eight potential connections, and an 8-position layout per row, making it suitable for the MKDS 3 product range. The terminal’s connection method utilizes screw connections with tension sleeves and L-slotted screw heads, requiring wave soldering for mounting. The conductor/PCB connection direction is at a 0-degree angle, and the terminals are colored green. A linear pinning layout accommodates five mm long solder pins per potential, with each pin connected to one potential. The product is packaged in cardboard and can be aligned to accommodate various numbers of positions.
