Phoenix Contact 1703083 PCB terminal block PTS 1,5/ 2-7,5-H Affordable

Phoenix Contact 1703083 A printed circuit board terminal has specifications such as a nominal current of 16 A and a rated voltage of 630 V with a cross-sectional area of 1.5 mm². The terminal features two potentials, one row, and two positions per row, falling within the product range PTS 1,5/..-H. The pitch distance is 7.5 mm, utilizing push-in spring connections for mounting through wave soldering. The conductor-to-PCB connection direction is at 0° with a green color, arranged in a linear pin layout, where each potential has one solder pin of 2.5 mm length.
