Description
Philadelphia Solar 600W (Pallet of 36) Bifacial Nexus N Type PS-MNB144(HBCF)-600W
FEOC Compliant
Built with 16BB half-cell technology and engineered using automated robotic production lines, this 600W module delivers strong front-side output with additional rear-side energy gains, reduced LCOE, and enhanced long-term reliability. Designed for commercial, industrial, and utility-scale applications, it offers excellent mechanical durability and weather resistance.
Key Technology
-
N-Type 16BB Half-Cell Architecture
Improves current collection, reduces resistive losses, and enhances performance under partial shading conditions. -
Bifacial Energy Generation
Up to 80% ±5% bifaciality ratio allows 5–25% additional power gain from the rear side depending on installation conditions. -
Exceptional Anti-PID Performance
Optimized mass-production process and strict material control ensure long-term durability and stability. -
High Mechanical Load Strength
Withstands 5400 Pa front and 2400 Pa rear static loads for demanding environments. -
Low Degradation & Positive Tolerance
Power tolerance of 0 ~ +3% and only -0.4% annual degradation for long-term energy yield.
Best Uses
-
Commercial & Industrial Rooftops
High power density reduces BOS costs for large rooftop systems. -
Utility-Scale Solar Plants
Ideal for ground-mount solar farms seeking maximum output and durability. -
Off-Grid & Hybrid Systems
Strong temperature performance and durability for harsh environments.
Warranty
- Product Warranty: 12 Years
- Performance Warranty: 30-Year Linear Power Warranty
- Performance at Year 12: 94.6% of rated output
- Performance at Year 30: 87.4% of rated output
- Annual Degradation: -0.4% per year
Product Specifications
| Specification | Details |
|---|---|
| Manufacturer | Philadelphia Solar |
| Series | NEXUS PS-MNB144(HBCF) |
| Model | PS-MNB144(HBCF)-600W |
| Cell Type | N-Type Mono-Crystalline, 16BB, Half-Cell |
| Cells per Module | 144 (72 × 2) |
| Maximum Power (Pmax) | 600 W |
| Module Efficiency | 23.23% |
| Maximum Power Voltage (Vmpp) | 44.57 V |
| Maximum Power Current (Impp) | 13.47 A |
| Open Circuit Voltage (Voc) | 52.21 V |
| Short Circuit Current (Isc) | 14.26 A |
| Bifaciality Ratio | 80% ±5% |
| Power Tolerance | 0 ~ +3% |
| Maximum System Voltage | 1500 V |
| Maximum Series Fuse | 30 A |
| Temperature Coefficient (Pmax) | -0.29% / °C |
| Temperature Coefficient (Voc) | -0.25% / °C |
| Temperature Coefficient (Isc) | +0.045% / °C |
| NOCT | 45 ±2 °C |
| Operating Temperature | IEC: -40 to +85°C / UL: -40 to +90°C |
| Module Dimensions | 89.72 × 44.65 × 1.18 in |
| Module Weight | 59.52 lb |
| Front Glass | 3.2 mm Tempered AR Coated Glass |
| Backsheet | Transparent Backsheet |
| Frame | Anodized Aluminum (Black/Silver) |
| Junction Box | IP68 with Original MC4 |
| Cable Length | 1200 mm (customizable) |
| Fire Classification | Type 1 |
| Modules per Pallet | 36 |
| Modules per 40′ HC Container | 720 |
| Mechanical Load (Front / Back) | 5400 Pa / 2400 Pa |
| Certifications | UL 61215 / UL 61730 / IEC 61215 / IEC 61730 / CSA C22.2#61730:2019 |
| Country of Manufacture | Jordan |
About Philadelphia Solar:
Philadelphia Solar is a global PV module manufacturer known for high-efficiency mono-crystalline and bifacial solar modules. Manufactured in Jordan using advanced automated production lines, their modules are engineered for durability, low degradation, and reliable long-term performance across commercial and utility-scale applications.
High-Power 600W Bifacial Module for Large-Scale Projects
The PS-MNB144(HBCF)-600W combines high efficiency, bifacial energy gains, and robust mechanical durability. With N-type half-cell technology, low annual degradation, and strong environmental resistance, it is an excellent choice for commercial rooftops and utility-scale solar installations focused on maximizing lifetime energy yield and ROI.
