Next Day Delivery Eaton E59-M12A105A01-A2 Inductive Proximity Sensor

Next Day Delivery Eaton E59-M12A105A01-A2 Inductive Proximity Sensor

Original price was: $352.83.Current price is: $141.13.

SKU: SK0223533-US20260519-084255 Category: Tag:

Description

Eaton E59-M12A105A01-A2 – Iprox Series Tubular Inductive Proximity Sensor Enclosure, 0.47 dia, Sensor dist 4 mm, 300 mA max AC, 2 – Wire AC, NC, 300 mA at 132 Vac, 3 Pin Dual Key Micro Connector

Specifications

Component
Inductive Proximity Sensor
(Instrument-Sensor) NEMA Protection
NEMA 4X
(Instrument-Sensor) IP Protection
IP67
(Instrument-Sensor) Size
M12
(Instrument-Sensor) Contact Configuration
1 NC
(Instrument-Sensor) IP Protection
IP69K
(Instrument-Sensor) Span
0 – 4 mm
(Instrument-Sensor) NEMA Protection
NEMA 4
(Instrument-Sensor) NEMA Protection
NEMA 13
(Instrument-Sensor) NEMA Protection
NEMA 6P
(Instrument-Sensor) NEMA Protection
NEMA 6
(Instrument-Sensor) NEMA Protection
NEMA 12
Manufacturer
Eaton
(Instrument-Sensor) Type
Tubular
(Instrument-Sensor) Connection Type
2 Wire
(Instrument-Sensor) Contact Rating
300 Ma At 132 VAC
(Instrument-Sensor) Supply Voltage
20-132 VAC
(Instrument-Sensor) Temperature Range
-40 °F – 158 °F
(Instrument-Sensor) Connection Type
3 Pin Dual Key Micro Connector
