Description
- Reliable Automatic Power Switching: Seamlessly transfers selected circuits from utility power to backup power during an outage—no manual intervention required.
- 50A Bus Bar with 30A Backup Support: Built with a 50A-rated bus bar for full-capacity handling of normal utility power, while safely limiting backup power to 30A. Compatible with most solar generators, battery backup systems, and gas generators. Supports 120V, 120/240V, and 120/208V systems, and is fully compatible with AFCI and GFCI breakers.
- Can Remain on Backup Power even after Utility Power Is Restored: The ATS does not have to automatically switch back to normal utility power, allowing continued use of backup power when desired.
- Essential Circuit Coverage: Manages up to 16 circuits, allowing essential appliances and systems to stay powered during outages.
- Durable, Heavy-Duty Enclosure: Built with a rugged enclosure designed for dependable performance and long-term reliability in demanding installation environments.
- Complete Connection & Control System: Includes a L14-30P 30A inlet and 30A power cord, plus a centralized control console for system monitoring, testing, and manual power source override.
- Certified for Safety & Code Compliance: Meets rigorous safety and performance standards including UL 1008 and CAN/CSA C22.2 No. 178.1, with documentation showing compliance under ISO/IEC Guide 17067.
Natures Generator Pre-Wired 30A Automatic Transfer Switch
| Power Rating | 30A |
|---|---|
| System Voltage | 120 V~ (L-N) / 208V~ (L-L) / 240V~ (L-L) |
| Number of Spaces | 8 spaces |
| Number of Circuits | Expandable to 16 circuits with tandem breakers |
| Dimension | 22 3/4 in x 14 1/4 in x 6 1/2 in |
| Weight | 48 lbs |
| Certification | UL 508A UL1008 CAN/CSA C22.2 No. 178.1 |
