Eaton E56ADL40UA Inductive Proximity Sensor Secure Checkout

Eaton E56ADL40UA Inductive Proximity Sensor Secure Checkout

Original price was: $398.74.Current price is: $159.50.

SKU: SK0223445-US20260519-084255 Category: Tag:

Description

Eaton E56ADL40UA – E56 Series Pancake Style Inductive Proximity Sensor, Sensor dist: 40 mm, 300 mA max DC, Complementary NPN/PNP Auto-configure, 300 mA at 42 Vdc, Screw Terminals, 10-42 Vdc input, < 2% accuracy, Auto reset, Un-shielded

Specifications

Component
Inductive Proximity Sensor
(Instrument-Sensor) NEMA Protection
NEMA 4X
(Instrument-Sensor) Connection Type
Screw Terminal
(Instrument-Sensor) IP Protection
IP67
(Instrument-Sensor) Type of Operator
NPN
(Instrument-Sensor) Type of Operator
PNP
(Instrument-Sensor) Span
0 – 40 mm
(Instrument-Sensor) NEMA Protection
NEMA 4
(Instrument-Sensor) NEMA Protection
NEMA 13
(Instrument-Sensor) NEMA Protection
NEMA 6P
(Instrument-Sensor) NEMA Protection
NEMA 6
(Instrument-Sensor) NEMA Protection
NEMA 12
Manufacturer
Eaton
(Instrument-Sensor) Temperature Range
-13 °F – 158 °F
(Instrument-Sensor) Contact Rating
300 Ma At 42 VDC
(Instrument-Sensor) Supply Voltage
10-42 VDC
