Description
The Xantrex Freedom XC 2000 Inverter/Charger offers premium performance in a lightweight compact package. This inverter/charger provides up to 2000 watts of continuous utility grade, pure sine wave power from a battery bank and is designed to handle loads such as microwave ovens, TVs, DVD/Blu-ray players, and power tools. In addition, the Freedom XC 2000’s extended 5 second high-surge capability lets you handle many hard-to-start loads, including full size residential refrigerators.
When AC power is available, the Freedom XC 2000 can operate as a 12 Volt battery charger. Different battery types and chemistries require different charging voltage levels, and not charging batteries at the required levels can shorten battery life or damage the batteries. The Freedom XC 2000 is configured at the factory with optimized charging algorithms to work with the battery types recommended for inverter applications. If the default settings do not work for your specific installation, you can adjust the charge stage settings through the inverter/charger’s custom battery settings menu.
The Freedom XC 2000 also has a built-in 30 Amp transfer switch that automatically transfers between inverter power and shore power from recreational facilities such as boat docks or campsites to ensure power is always available. If incoming shore power is interrupted by external events like brownouts, the Freedom XC 2000 automatically becomes an independent power source that supplies utility grade AC power to your loads.
The Freedom XC 2000 offers comprehensive built-in protection features to safeguard your batteries from unnecessary drain while protecting your equipment. Features include selectable low battery shutdown voltage, low voltage shutdown delay timer, power save mode, low battery voltage alarm and shutdown. The Freedom XC 2000 also features configurable AC transfer speed, output frequency, and voltage, making it extremely versatile.
-
Inverter Specifications Input 12 VDC Output voltage 120 VAC, 60 Hz Continuous Power 2000 W (16.8 A) Surge Power 4000 W (33.6 A), 2 Seconds Output waveform Pure sine wave Transfer relay 30 A Charger Specifications Input 120 VAC, 60 Hz Output Current 5-80 ADC, user selectable Output voltage 18 VDC maximum General Specifications Dimensions 15.4 x 10.8 x 4.0 in (390 x 275 x 102 mm) Inverter weight 16.3 lbs (7.4 kg) Shipping weight 19.0 lbs (8.6 kg) Warranty 2 years - See spec sheet for additional info
